Preparing the system for Zabbix
Before installing any Zabbix component, we need to ensure that the server(s) meet the configuration requirements outlined in the previous section: System Requirements.
If you plan to install the Zabbix database, server and/or frontend on separate machines, prepare each server individually according to the instructions provided here. Also servers that will host a Zabbix Proxy, need to be prepared in the same way.
Disable SELinux on RHEL
Another critical step at this stage if you use Red Hat based systems is disabling SELinux, which can interfere with the installation and operation of Zabbix. We will revisit SELinux at the end of this chapter once our installation is finished.
To check the current status of SELinux, you can use the following command: `sestatus``
Selinux status
~# sestatus
SELinux status: enabled
SELinuxfs mount: /sys/fs/selinux
SELinux root directory: /etc/selinux
Loaded policy name: targeted
Current mode: enforcing
Mode from config file: enforcing
Policy MLS status: enabled
Policy deny_unknown status: allowed
Memory protection checking: actual (secure)
Max kernel policy version: 33
As shown, the system is currently in enforcing mode. To temporarily disable SELinux,
you can run the following command: setenforce 0
Disable SeLinux
~# setenforce 0
~# sestatus
SELinux status: enabled
SELinuxfs mount: /sys/fs/selinux
SELinux root directory: /etc/selinux
Loaded policy name: targeted
Current mode: permissive
Mode from config file: enforcing
Policy MLS status: enabled
Policy deny_unknown status: allowed
Memory protection checking: actual (secure)
Max kernel policy version: 33
Now, as you can see, the mode is switched to permissive. However, this change
is not persistent across reboots. To make it permanent, you need to modify the
SELinux configuration file located at /etc/selinux/config. Open the file and
replace enforcing with permissive.
Alternatively, you can achieve the same result more easily by running the following command:
Disable SeLinux permanent
Red Hat
This line will alter the configuration file for you. So when we run sestatus
again we will see that we are in permissive mode and that our configuration
file is also in permissive mode.
Verify selinux status again
~# sestatus
SELinux status: enabled
SELinuxfs mount: /sys/fs/selinux
SELinux root directory: /etc/selinux
Loaded policy name: targeted
Current mode: permissive
Mode from config file: permissive
Policy MLS status: enabled
Policy deny_unknown status: allowed
Memory protection checking: actual (secure)
Max kernel policy version: 33
Install the Zabbix repository
From the Zabbix Download page https://www.zabbix.com/download, select the appropriate Zabbix version you wish to install. In this case, we will be using Zabbix 8.0 LTS. Additionally, ensure you choose the correct OS distribution for your environment, which will be Rocky Linux 9, openSUSE Leap 16 or Ubuntu 24.04 in our case.
We will be installing the Zabbix Server along with NGINX as the web server for the front-end. Make sure to download the relevant packages for your chosen configuration.
1.2 Zabbix download
Red Hat specific remarks
If you make use of a RHEL based system like Rocky then the first step is to disable
the Zabbix packages provided by the EPEL repository, if it's installed on your system.
To do this, edit the /etc/yum.repos.d/epel.repo file and add the following statement
to disable the EPEL repository by default:
Tip
It's considered bad practice to keep the EPEL repository enabled all the time,
as it may cause conflicts by unintentionally overwriting or installing unwanted
packages. Instead, it's safer to enable the repository only when needed, by using
the following command during installations: dnf install --enablerepo=epel
OpenSUSE specific remarks
On openSUSE, Zabbix packages are also available in the default repo-oss repository.
Unlike RHEL-based systems, openSUSE does not provide a built-in way to exclude
specific packages from individual repositories. However, the Zabbix packages
included in the default repositories are typically one to two LTS versions behind
the latest releases. As a result, they are unlikely to interfere with your
installation unless they are already installed.
In the next step, we will configure the official Zabbix repositories. As long
as you select a Zabbix repository version newer than the packages available in
repo-oss, zypper will automatically install the most recent version.
Tip
If you have already installed Zabbix packages from the default repositories, it is recommended to either:
- Remove them before proceeding, or
- Upgrade them after adding the new Zabbix repositories, using the zypper
option
--allow-vendor-change.
Suse Linux Enterprise Server (SLES)
If you are using SLES, the Zabbix packages are not included in the default repositories. Therefore, you can proceed to add the official Zabbix repository without any concerns about conflicts with existing packages.
Adding the Zabbix repository
Next, we will install the Zabbix repository on our operating system. After adding the Zabbix repository, it is recommended to perform a repository cleanup to remove old cache files and ensure the repository metadata is up to date. You can do this by running:
Add the zabbix repo
Red Hat
rpm -Uvh https://repo.zabbix.com/zabbix/8.0/release/rocky/9/noarch/zabbix-release-latest-8.0.el9.noarch.rpm
dnf clean all
SUSE
rpm -Uvh --nosignature https://repo.zabbix.com/zabbix/8.0/release/sles/16/noarch/zabbix-release-latest-8.0.sles16.noarch.rpm
zypper --gpg-auto-import-keys refresh 'Zabbix Official Repository'
# Set the repository to auto-refresh to ensure it's always up to date
zypper modifyrepo --refresh 'Zabbix Official Repository'
Ubuntu
This will refresh the repository metadata and prepare the system for Zabbix installation.
What is a repository?
A repository in Linux is a configuration that allows you to access and install software packages. You can think of it like an "app store" where you find and download software from a trusted source, in this case, the Zabbix repository. Many repositories are available, but it's important to only add those you trust. The safest practice is to stick to the repositories provided by your operating system and only add additional ones when you're sure they are both trusted and necessary.
For our installation, the Zabbix repository is provided by the vendor itself, making it a trusted source. Another popular and safe repository for Red Hat-based systems is EPEL (Extra Packages for Enterprise Linux), which is commonly used in enterprise environments. However, always exercise caution when adding new repositories to ensure system security and stability.
Preparing the system for running containers using Podman
If you plan to run Zabbix components as containers using Podman, you need to ensure that Podman is installed and properly configured on your system. Below are the instructions for installing Podman on different operating systems.
You can skip this section if you do not plan to run any Zabbix components as containers on the current system.
Why Podman?
Podman is a popular containerization tool that allows you to run and manage containers without requiring a daemon like Docker. It is the recommended container engine on most modern distributions and offers several advantages over Docker.
Firstly, Podman enhances security by supporting rootless containers, allowing containers to run under non-privileged user accounts. Secondly, it integrates seamlessly with SELinux, enabling robust access control and policy enforcement. Thirdly, Podman works natively with systemd, which facilitates container lifecycle management through systemd units and quadlets.
Installing Podman
To be able to run containers using Podman, we first need to install Podman and some additional tools that will help us manage containers with SystemD.
Install podman and needed tools
Red Hat
SUSE
Ubuntu
Configure Podman for user-based container management
Next, we will create a podman-user which will be running the container(s). You
are free to use a different username, e.g. zabbix-proxy for a user that will
be running only zabbix-proxy in a container.
Create and init podman user
When your system has SELinux enabled, execute the following command as root.
SELinux: Set file context mapping
This command adds a SELinux file context mapping by creating an equivalence (-e)
between the default container storage directory /var/lib/containers and the user’s
Podman container storage path /home/podman/.local/share/containers. Essentially,
it tells SELinux to treat files in the user's container storage the same way it
treats files in the default system container storage, ensuring proper access
permissions under SELinux policy.
After defining new SELinux contexts, this command recursively (-R) applies
the correct SELinux security contexts to the files in the specified directory.
The -v flag enables verbose output, showing what changes are made. This ensures
that all files in the container storage directory have the correct SELinux labels
as defined by the previous semanage commands.
This command enables “linger” for the user podman. Linger allows user services
(such as containers managed by SystemD) to continue running even when the user
is not actively logged in. This is useful for running Podman containers in the
background and ensures that containerized proxies or other services remain active
after logout or system reboots.
As the final step in creating the Podman setup we need to to tell SystemD where the user-specific runtime files are stored:
Set XDG_RUNTIME_DIR environment variable for podman user
This line ensures that the XDG_RUNTIME_DIR environment variable is correctly set
for the podman user and is loaded in current and next sessions.
This variable points to the location where user-specific runtime
files are stored, including the systemd user session bus. Setting it is essential
for enabling systemctl --user to function properly with Podman-managed containers.
Your system is now prepared for running Zabbix components as containers using Podman.
Known issue waiting for network-online.target
In case the starting of your containers takes about 90s and then ultimately
fails to start. If you then see lines like this in your system logging
(journalctl):
systemd[1601]: Starting Wait for system level network-online.target as user....
sh[3128]: inactive
sh[3130]: inactive
sh[3132]: inactive
sh[3134]: inactive
sh[3136]: inactive
...
...
sh[3604]: inactive
sh[3606]: inactive
systemd[1601]: podman-user-wait-network-online.service: start operation timed out. Terminating.
systemd[1601]: podman-user-wait-network-online.service: Main process exited, code=killed, status=15/TERM
systemd[1601]: podman-user-wait-network-online.service: Failed with result 'timeout'.
systemd[1601]: Failed to start Wait for system level network-online.target as user..
Then you are hitting a known problem with the Podman Quadlets.
This is caused by the fact that the SystemD generated Quadlet service contains
a dependency to the system-wide special target network-online.target which
normally indicates the system's network is fully up and running. However on
certain Linux distriutions or with specific networking configurations the
system network components may not correctly notify SystemD that the network is
"online", causing network-online.target to never get activated. This in turn
makes that Podman will wait until it times out, thinking the network is not
yet available.
As a workaround, you can create a dummy system service that will trigger
network-online.target:
Known issue waiting for network-online.target
In case the starting of your containers takes about 90s and then ultimately
fail to start. If you then see lines like this in your system logging
(journalctl):
systemd[1601]: Starting Wait for system level network-online.target as user....
sh[3128]: inactive
sh[3130]: inactive
sh[3132]: inactive
sh[3134]: inactive
sh[3136]: inactive
...
...
sh[3604]: inactive
sh[3606]: inactive
systemd[1601]: podman-user-wait-network-online.service: start operation timed out. Terminating.
systemd[1601]: podman-user-wait-network-online.service: Main process exited, code=killed, status=15/TERM
systemd[1601]: podman-user-wait-network-online.service: Failed with result 'timeout'.
systemd[1601]: Failed to start Wait for system level network-online.target as user..
Then you are hitting a known problem with the Podman Quadlets.
This is caused by the fact that the SystemD generated Quadlet service contains
a dependency to the system-wide special target network-online.target which
normally indicates the system's network is fully up and running. However on
certain Linux distriutions or with specific networking configurations the
system network components may not correctly notify SystemD that the network is
"online", causing network-online.target to never get activated. This in turn
makes that Podman will wait until it times out, thinking the network is not
yet available.
As a workaround, you can create a dummy system service that will trigger
network-online.target:
Conclusion
With the preparation of your system for Zabbix now complete, you have successfully configured your environment for the installation of Zabbix components. We've covered the steps to add the official Zabbix repository to your system, preparing it for the installation of Zabbix server, database, and frontend components. And we have also prepared the system for running containers using Podman, if needed.
Your system is now ready for the next steps. In the following chapter, we will delve into the installation of the Zabbix components, guiding you through the process of setting up the Zabbix server, database, and frontend.
